SF3252 ONE CABLE SOLUTION LNBF Vinfostar 抗5G干扰高频头

INPUT FREQUENCY

3.8～4.2 GHz

L.O. FREQUENCY

5.15 GHz ± 1 MHz5.75 GHz ± 1 MHz

STABILITY

±2 MHz(-40 ℃ ～ +70 ℃)

L.O. PHASE NOISE

-55 dBc/Hz@1KHz
-85 dBc/Hz@10KHz
-105 dBc/Hz@100KHz

OUTPUT FREQUENCY

H 950~1350 MHzV 1950~2050 MHz

CONVERSION GAIN

67 dB (TYP)

GAIN FLATNESS

±0.5 dB/36 MHz

NOISE FIGURE

50°K

INPUT V.S.W.R

2.5:1

OUTPUT V.S.W.R

2.5:1

LOCAL LEAKAGEAT INPUT

-45 dBm

IMAGE REJECTION

50 dB

OUTPUT POWER

+ 5 dBm (AT 1 dB COMPRESSION)

CROSS POLAR ISOLATION

23dB MIN

DC SUPPLY VOLTAGE

15.5-22 V

SUPPLY CURRENT

180 mA (MAX)

OPERATING TEMPERATURE

-40 ℃ ～ +70 ℃

RELATIVE HUMIDITY

0%～95%

RF INPUT CONNECTER

WAVE GUIDE WC-229

IF OUTPUT CONNECTER

"F" TYPE FEMALE

OUTPUT IMPEDANCE

75 OHMS
