10-16GHz 高频头 降频器 GX1016K 下变频器

2)  Ku down converter

                Part no.:        GX1016K

Input frequency:  10~16GHz, divided into six bands, e.g.:

                                i) 10~11.2GHz,          ii) 11.0~12.2GHz,    iii) 12.0~13.2GHz,

iv) 13.0~14.2GHz,    v) 14.0~15.2GHz,      vi) 15.0~16GHz

Output frequency:  950~2150MHz.

LO:            6 LO switchable

i) 9.05GHz,         ii) 10.05GHz,             iii) 11.05GHz,

  iv) 12.05GHz,       v) 13.05GHz,             vi) 14.05GHz

Output P1dB:     10dBm.

Gain:           25dB.

Gain adjustment:  Range of 0~30dB, with a step of 0.5dB.

Input VSWR:     ≤3.0:1. Output VSWR:   ≤2.0:1.

Phase noise:      -60dBc/Hz@100Hz, -70dBc/Hz@1kHz,

-80dBc/Hz@10kHz,

-90dBc/Hz@100kHz.

Interfaces:                Input SMA-K.

Output SMA-K.

PS and M&C aviation socket, RS232.

Power supply:    DC 12~24V, ≤300mA.

Dimensions:     188×110×29.5mm.

Weight:         ≤1.1kg,

Ref. requirements: Internal or external reference auto-sensing.

Freq. stability ±1ppm @internal ref.

External ref. 10MHz, 0±3dBm. Working temperature: -40°C ~ +60°C.
