Ext. Ka-Band 2-Port Feed Combiner Assembly

For Offset VSAT Antenna, f/d = 0.8

Model: DH-FEED-Ext.Ka-RXO-F/D=0.8

Product Overview

This external Ka-band dual-port feed combiner assembly is designed for offset parabolic VSAT antennas with an f/d ratio of 0.8. It enables simultaneous reception (Rx) over two ports while maintaining high isolation and polarization control — ideal for dual-LNB or diversity reception systems in satellite communications.

Technical Specifications

Applications

• Ka-band VSAT satellite communication systems

• Dual-LNB or diversity reception setups

• Offset parabolic reflectors (f/d = 0.8)

• Ground station, maritime, or mobile satellite terminals

Features & Benefits

• High Port Isolation: 35 dB min. ensures minimal interference between Rx channels

• Manual Polarization Switching: RHCP/LHCP/HLP/VLP selectable for flexible system configuration

• Compact Design: Standard waveguide interface (WR-42/R220) for easy integration

• Rugged Construction: Aluminum with conductive oxidation + white paint finish for outdoor durability

• Optimized Illumination: 60° aperture for efficient reflector coupling at f/d = 0.8

• High Power Handling: Supports up to 100W continuous wave (CW)

Ordering Information

Model: DH-FEED-Ext.Ka-RXO-F/D=0.8

Configuration: Standard white paint finish; custom colors or finishes available upon request

Accessories: Optional mounting brackets, dust caps, or LNB adapters (contact factory)

Compliance & Notes

• Designed for outdoor use within specified environmental limits

• Rx-only unit; not intended for transmit (Tx) applications

• Contact factory for extended temperature or military-grade variants
