Intelligent Microwave Transmission Platform

智能微波传输平台

Shenzhen Huashi Digital Technology Co., Ltd. provides the intelligent microwave transmission platform.

深圳市华视数码科技有限公司提供智能微波传输平台。

The GH1000 series is a powerful product suite suitable for satellite communications, remote sensing, navigation and positioning, EMC, TT&C, broadcasting, emergency response, low-altitude economy, and other fields. Covering IF, P, S, C, X, Ku, Ka bands, it supports both remote and local control, features voltage/current alarm protection, and supports multi-channel hot-swappable expansion up to 4/8/16/32/64/128 channels. It can be configured with a 1:N backup system.

GH1000系列产品功能强大，适应于卫星通信、遥感探测、导航定位、电磁兼容、航天测控、广播电视、应急保障、低空经济等多个领域。产品覆盖IF、P、S、C、X、Ku、Ka等频段，支持远程控制和设备本机控制，具有电压、电流告警告警保护功能，支持多路拔插，容量扩展最大可至4通道/8通道/16通道/32通道/64通道/128通道，可配置1：N备份系统进行使用。

The intelligent microwave transmission platform integrates frequency conversion, line amplification, photoelectric conversion, and dual-power supply functions.

智能微波传输平台，可实现信号的变频、线路放大、光电转换,双电源等功能。

The GH1000 series adopts hot-swap technology, allowing plug-and-play operation for easy maintenance and replacement. It features automatic board identification, automatic parameter reading, automatic link gain calculation and allocation, and supports visualization.

GH1000系列产品采用热插拔技术，板卡即插即用，便于维护和替换，可自动识别板卡身份、自动读取参数，实现链路增益的自动计算分配，且支持图视化。

• 可定制本振、时钟频率 / Customizable local oscillator and clock frequency




• 各频率信号相互锁相 / The frequency signals lock each other




• 极低的附加抖动恶化 / Extremely low additional jitter deterioration




• 可定制多通道输出 / Customizable multichannel output




Technical Features | 技术特点

＊ Support fast board hot-swapping / 支持板卡快速热插拔

＊ Multi-function compatibility / 多功能兼容

＊ Multi-band coexistence / 多频段共存

＊ Supports host computer graphical OS / 支持上位机图示化操作系统

＊ Automatic board ID recognition & parameter reading / 板卡身份自动识别，参数自动读取

＊ Automatic link gain calculation & allocation / 链路增益自动计算分配

＊ Domestic components (controllable) or imported components available / 元器件国产化自主可控（也可以进口器件）

Optional Functions | 可选功能

＊ Configurable 1:N redundant backup system / 可配置1:N冗余备份系统

Notes | 说明

The above specifications are typical values. Parameters for this product series can be customized.

以上指标为典型值，此系列产品参数可定制。

Notes | 说明

The product comes with racks; custom designs are supported. Contact us for full details.

该产品有货架配置，也可以为客户定制设计产品，详细细节请联系我司18688706870。
